USB Type-C 4 40Gbps Certified Cable 0.8m - PF587A
USB4 0.8m cable: 40Gbps, 100W PD, DP1.4 8K video, Thunderbolt 3 compatible, backward compatible with USB 3.2/2.0.
Overview
The PF587A is a USB4 cable built to the USB Association's latest specification. It is compatible with Thunderbolt 3 and backward compatible with USB 3.2 and USB 2.0, supporting 100W PD power delivery and 40Gbps bandwidth.
It can carry DP1.4 8K video specifications, making it a preferred ultra-fast data and video cable for the full range of Intel EVO laptops and MacBooks. It carries an E-Mark chip and outputs DisplayPort A/V signal at up to 8K@60Hz.
Construction uses TPE injection, nickel-plated connectors, a coaxial design and TPE jacket. The box contains one cable.
Specifications
| Spec | Value |
|---|---|
| Model / Code | PF587A |
| Cable Material | TPE |
| Color | Black |
| Shell Material | Molding |
| Connector | USB-C |
| Length | 0.8 m |
| Standard | USB4 (Thunderbolt 3 compatible) |
| Bandwidth | 40Gbps |
| Power Delivery | 100W USB-C |
| Video | DP1.4, up to 8K@60Hz |
| Chip | E-Mark |
Frequently Asked Questions
- Is the PF587A compatible with Thunderbolt 3?
- Yes, and it is backward compatible with USB 3.2 and USB 2.0.
- What is the PF587A bandwidth and power?
- 40Gbps bandwidth and 100W PD power delivery.
- Can the PF587A carry 8K video?
- Yes, it supports DP1.4 video up to 8K@60Hz.
- What devices is the PF587A designed for?
- Intel EVO laptops and MacBooks needing fast USB4 data and video.
